1x4 35W Multi Watt Multi CCT LED Designer Troffer
1x4 35W Multi Watt Multi CCT LED Designer Troffer
LUXRITE
SKU:
Specifications:
|
Size: 1x4 |
Dimensions: 47.72" x 11.77" x 1.74" |
|
Wattage: 25W/30W/35W (Selectable) |
IP Rating: IP20 |
|
Product CCT: 3500K/4000K/5000K (Selectable) |
Total Lumens: 2750 lm (25W), 3300 lm (30W), 3850 lm (35W) |
|
Input Voltage Range: 100-277V |
Product Efficacy (Min): 110 lm/W |
|
Dimming: 1 -10V |
Lens Material: PMMA |
|
Product CRI: 80 |
Certifications: IC Rated |
|
Driver Type (CC/CV): Constant Current |
|
Description
Overview
The Luxrite LED Lay-In Designer Panel Center Lens series offers high-performance lighting for commercial and residential spaces. Available in 1x4, 2x2, and 2x4 sizes, these panels feature selectable CCT (3500K, 4000K, 5000K) and adjustable wattage for flexible installation. With a sleek design, superior energy efficiency of 110 lm/W, and a 50,000-hour lifetime, they are ideal for modern lighting solutions.
The panels are UL Listed for safety and compatibility with 110-277V systems. Selectable power options ensure optimal brightness for varying applications.
Features
• Color Selectable: Choose from 3500K, 4000K, or 5000K.
• Wattage Adjustable: Adjustable wattages for maximum flexibility.
• High Efficacy: Delivers up to 110 lumens per watt.
• Long Lifetime: 50,000-hour rated life ensures long-term reliability.
• UL Listed: Certified for safety and compliance.
• CRI 80: High color rendering for clear, vibrant illumination.
• Dimmable: 1-10V dimming capability.
• Emergency Compatibility: Compatible with LR35126 Emergency LED Driver.
