180-320W Multi Watt Multi CCT Area Light

180-320W Multi Watt Multi CCT Area Light

LEDone

SKU:

Specifications:

Dimensions: 22.36 in x 14.02 in x 2.64

Multi Lens: T3, T4 and T5

Wattage: 180/200/240/320W (Selectable)

Surge Projection (CM): 10 KV

Dimming: 0-10V

Default Lens Type: Type III

Input Voltage Range: 120 - 277V or 347 - 480V

Average life: 50000 hrs

Input Frequency: 50/60 Hz

Operating Temperature: -40°C to +40°C (-40°F to 104°F)

Power Factor: 0.9

Product CRI: 83

THD: 15%

IP Rating: IP65

Total Lumens (Min): 20001-30000, >30001

Product Ecacy (Min): 145.6 lm/W

Product Beam Angle: 120°

Product CCT: 3500K/4000K/5000K (Selectable)

Housing Material: Die-Cast Aluminum

LED Package: Lumileds 2835 LED chips

Bug Rating: B4-U0-G4



View full details

Description

Overview

This Area Light offers a versatile and energy-efficient lighting solution for various outdoor applications. With selectable wattages of 180W, 200W, 240W, and 320W, and color temperatures of 3000K, 4000K, and 5000K, this fixture allows for customization to meet specific lighting requirements. Its compatibility with Type III, IV, and V optics ensures optimal light distribution for different environments. Designed for durability, it features an IP65-rated housing, making it suitable for wet locations, and operates within a voltage range of 120–277V. Ideal for parking lots, campuses, and commercial outdoor spaces, the ALAL Series combines performance with flexibility.

Features

• Adjustable lens: Type III, Type IV or Type V.
• Lumileds 2835 LED Chips.
• Full cut off.
• Bronze die-cast aluminum housing treated by anodic oxidation.
• Easy installation and maintenance.
• Corrosion and rust proof.
