Mini LED Exit Sign Emergency Light Combo

The MINI-C-WR is constructed with a flame and corrosion resistant 5VA thermoplastic housing in a standard white finish. It includes two removable green 'EXIT' stencil faceplates and a solid backplate, for single or double sided application. The stencil plates have knockout directional chevrons (arrows), and will adapt to any exit strategy.

The Red LED Exit Emergency Light Combo also includes a universal mounting plate and canopy that allows for ceiling, end or back installation. On either side of the sign are square plastic LED emergency lamp heads. They can be aimed and locked at any angle in a full 360° axis.

This MINI-C-WR model includes a 6-volt Nickel Cadmium (Ni-Cd) battery pack. These AAA sized batteries will power the lights and sign for a minimum of 90 minutes per UL924 code.

A push-to-test switch and LED pilot light on the bottom of the exit sign housing allows you to test the emergency readiness of the fixture. The LED will flash if any fault is detected in the circuit, LED lights or battery.

• Damp rated, flame resistant thermoplastic housing with a white finish.
• Includes two (2) stencils, one (1) backplate and one (1) mounting canopy.
• Energy efficient Green LEDs.
• Two (2) adjustable square lighting heads with (7) LEDs each.
• Knockout directional chevrons.
• Dual primary 120 or 277 VAC operation.
• UL Listed for damp locations.
• Includes 6V Nickel Cadmium battery pack.
• Fully automatic solid-state, two-rate charger.
